Product Details:
Payment & Shipping Terms:
|
Package: | 1 Piece Per Carton | Paint Finish: | Epoxy Polyester Coating |
---|---|---|---|
Accessories: | Wall Mount Brackets To Be Offered Seperately | Material: | Stainless Steel |
Protection Leve: | IP66 | Thickness: | 1.5/2.0/2.0 |
JXF Stainless Steel Bending Cabinet Power Distribution Cabinet
Process characteristics and properties:
Optional configuration: non - standard imitation cabinet shell can be made outdoor type can do anti - rain shed, side board (can be discounted), computer trailing board, threshold position, door support, light, longitudinal beam, file bag;
Material: non-standard imitation cabinets cabinet, the installation plate is galvanized sheet, material thickness door plate 2.0mm, installation board 2.5mm, cabinet body is 1.5mm;
1) the door hinge is concealed and can be opened to 130 degrees, so it is easy to install and replace.
2) the three cover plates of the floor entry holes can be replaced with each other, freely moving to facilitate the import of cables and opening of holes.
3) the installation plate is made of 2.5mm thickness cold plate, galvanized or spray painted.
4) the door plate is made of polyurethane foam sealant strips for cold rolled plates, and the required protection level can be obtained. The front and rear doors can be made single or double.
5) surface treatment: degreasing, phosphating, pickling, outdoor waterproof plastic powder.
6) color: RAL7032 or RAL7035 and optional color.
Standard | Height(mm) | Width(mm) | Depth(mm) | Thickness |
JXF | 1500 | 600 | 350 | 1.5/2.0/1.5 |
1700 | 700 | 350 | 1.5/2.0/2.0 | |
1700 | 700 | 400 | 1.5/2.0/2.0 | |
1800 | 800 | 400 | 1.5/2.5/2.0 | |
1800 | 800 | 450 | 1.5/2.5/2.0 | |
2000 | 800 | 600 | 2.0/2.5/2.0 |
Product name | Distribution box |
Material | Sheet Steel |
OEM | Offered |
Package | 1 Piece Per Carton |
Certification | CE,CCC,ROHS,TUS |
Paint Finish | Epoxy Polyester Coating |
Lock | Available On Request |
Thckness | 1.5/2.0/1.5 |
Color | Ral7035 |
Accessories | Wall Mount Brackets To Be Offered Seperately |
