Outdoor Telecom Power Distribution Equipment Fiber Optic Power Distribution Box 3 Phase

China Outdoor Telecom Power Distribution Equipment Fiber Optic Power Distribution Box 3 Phase supplier
Outdoor Telecom Power Distribution Equipment Fiber Optic Power Distribution Box 3 Phase supplier Outdoor Telecom Power Distribution Equipment Fiber Optic Power Distribution Box 3 Phase supplier

Large Image :  Outdoor Telecom Power Distribution Equipment Fiber Optic Power Distribution Box 3 Phase

Product Details:

Place of Origin: China
Brand Name: QK
Certification: RoHS, CE, UL,CCC,ISO9001
Model Number: 70-170-37 opening

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece
Price: Negotiation
Packaging Details: Regular export packing and can accept customized
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 1000 Pieces/month
Contact Now
Detailed Product Description
Package: 1 Piece Per Carton Paint Finish: Epoxy Polyester Coating
Accessories: Wall Mount Brackets To Be Offered Seperately Material: Stainless Steel
Protection Leve: IP66 Thickness: 1.5/2.0/2.0

JXF Stainless Steel Bending Cabinet Power Distribution Cabinet




Process performance and features
  •  mounting plate distance can move from back and forth to adjust depth.
  •  the down hole have cover board ,it is easy to disassemble the front and back doors
  •  The three bottom cover boards can be exchanged each other,free movement.easy to import  cable, open the hole into the line.
  •  The base  is easy to assemble and disassemble(choose by your self)
  •  surface preparation:degreasing, phosphating, electrophoresis primer, outdoor    waterproof cover powder.
  •  Main color:RAL7032  mounting plate:orange color or galvanization.mounting plate:2.5mm.
  •  According to the customers requirements,we can make different specifications.



Process characteristics and properties:

1)  the cabinet body skeleton adopts ten percent off type section, the circular hole or square hole of each interval 25mm of the beforehand perforated bar makes the internal installation more convenient, the special quality three passes welded into the whole, the structure is firm and reliable, the shape is beautiful.

2)  the installation board can be 25mm for the unit distance, move back and forth, adjust the depth.

3)  the top cover, side plate, back plate and base floor are all fixed by screws, which is easy to assemble and disassemble, and the installation work inside the cabinet is more convenient and fast.

4)  the door hinge is concealed and can be opened to 130 degrees, so it is easy to install and replace.

5)  the three cover plates of the floor entry holes can be replaced with each other, freely moving to facilitate the import of cables and opening of holes.

6)  the installation plate is made of 2.5mm thickness cold plate, galvanized or spray painted.

7)  the door plate is made of polyurethane foam sealant strips for cold rolled plates, and the required protection level can be obtained. The front and rear doors can be made single or double.

8)  surface treatment: degreasing, phosphating, pickling, outdoor waterproof plastic powder.

9)  color: RAL7032 or RAL7035 and optional color.



Standard Height(mm) Width(mm) Depth(mm) Thickness
JXF 1500 600 350 1.5/2.0/1.5
1700 700 350 1.5/2.0/2.0
1700 700 400 1.5/2.0/2.0
1800 800 400 1.5/2.5/2.0
1800 800 450 1.5/2.5/2.0
2000 800 600 2.0/2.5/2.0





Characteristic



 Product name  Distribution box
 Material Sheet Steel
 OEM  Offered
Package  1 Piece Per Carton
Certification  CE,CCC,ROHS,TUS
Paint Finish  Epoxy Polyester Coating
Lock  Available On Request
Thckness  1.5/2.0/1.5
Color Ral7035
Accessories Wall Mount Brackets To Be Offered Seperately



Outdoor Telecom Power Distribution Equipment Fiber Optic Power Distribution Box 3 Phase
